Nissan Silvia S14 / S15 with RB & JZ Fan Shroud Kit [Tucked]

Shroud Dimensions: 578mm x 378mm x 20mm.
Fan Dimensions:
[Fenix] 14" / 350mm x 370mm x 70mm.
[SPAL] 14" / 332mm x 366mm x 62mm.

Direct replacement for Fenix Radiator part no:

FTS0003-56M / -BL [Tucked].

1993-98 Nissan Silvia / 200SX S14 fitted with 2.0L RB20DET / DE & 2.5L RB25DET / DE or 2.5L 1JZ-GTE & 3.0L 2JZ-GTE.

1999-02 Nissan Silvia / 200SX S15 fitted with 2.0L RB20DET/DE & 2.5L RB25DET/DE or 2.5L 1JZ-GTE & 3.0L 2JZ-GTE.
Transmission: Manual.

• LHS option suits: Toyota 1JZ & 2JZ engines.
• Centre option suits: V8 & Nissan SR20 engines.
• RHS option suits: Nissan RB engines*.

Features [Shroud]:

• Full Aluminium construction.
• Raw alloy or powder coated finish.
• Manufactured in New Zealand.
• Left, centre or right fan position.

Features [Fenix Fan]:
• Curved blades for maximum efficiency.
• Lightweight ABS construction.
• 12V / 90W Electric motor.

Features [SPAL]:
• Pull type [non-reversible].
• Curved blades for maximum efficiency.
• IP68 Water & Dust resistant 12v motor.
• 310CFM / 2220m3/h rated.
• Lifetime 6,000 > 8,000 hours [RB Only].
• Slimline design.
• Made in Italy.

NOTE: Fans do not use OEM connectors. We recommend this kit is installed by a professional mechanic or auto electrician. Original A/C mounts may require removal / minor modification depending on vehicle. *RB engines must be mounted as far back as possible for clearance.

Special Order options are made to order and can take up to 2 weeks to produce. Contact us prior to purchasing If your order is urgent.

_______________________________________________________________________

Upgrade your old, stock fan shroud with a Fenix Performance Nissan Fan Shroud Kit. Designed with performance and reliability in mind, our alloy fan shroud kits significantly increase the cooling ability on the track or street while offering a factory fit to your oem or Fenix Performance Alloy Radiator.

*Core size is tube and fin area only and does not include tanks or plate under tank.
